Type =
Nickel
Type Formula = YR 8 SEU
Heat Range = 8
Spanner Size = 16
Thread Length (mm) = 26.5
Thread Diameter (mm) = 12
Thread Pitch (mm) = 1.25
Centre Electrode Connection Material = NiY+Cu
Centre Electrode Material = NiY
Ground Electrode Material = NiY
Spark Position (mm) = 5
Gap (mm) = 1
Center Electrode ( mm ) = 2.3
NO. Poles = 1
Resistance (Kohm) = 6
Tightning Angle = 90
Tightening Torque (N.m) = 23
Type of Connection = Non Detachable DIN/SAE Head
Chery - Arrizo 5 1.5 (2015-)
Chery - Tiggo 3 1.6 (2013-)
Hyundai - Accent IV RB 1.6 (2010-)
Hyundai - Creta 1.6 (2014-) (ix25)
Hyundai - Elantra AD 1.6 (2016-)
Hyundai - Elantra HD 1.6 (2010-)
Hyundai - Elantra MD 1.6 (2011-2016)
Hyundai - Solaris 1.4 (2010-2015) RB
Hyundai - Veloster 1.6 MPI (2012-)
Hyundai - i10 Grand 1.2 (2016-)
Hyundai - i20 1.4 (2010-2014)
Hyundai - i20 1.4 (2015-)
Hyundai - i30 1.6 (2010-2011)
Hyundai - i30 1.6 (2012-) CW / Estate
Hyundai - i30 1.6 (2012-) Hatchback
Hyundai - ix20 1.6 (2010-2015)
Hyundai - ix20 1.6 (2016-)
Hyundai - ix35 1.6 (2009-2016)
Kia - Carens 1.6 (2006-2013)
Kia - Cee'd 1.6 CVVT (2014-)
Kia - Cerato 1.6 (2010-2013)
Kia - Cerato Forte 1.6 (2010-2013)
Kia - Cerato Grand 1.6 (2018-)
Kia - Cerato Koup 1.6 (2010-2017)
Kia - Pegas 1.4 (2018-)
Kia - Picanto 1.0 (2012-2016)
Kia - Picanto 1.0 (2017-)
Kia - Picanto 1.2 (2012-2016)
Kia - Picanto 1.2 (2017-)
Kia - Rio III 1.4 (2012-2017)
Kia - Rio III 1.6 (2012-2017)
Kia - Rio IV 1.4 (2018-)
Kia - Rio IV 1.6 (2018-)
Kia - Sorento II 3.5 2WD/4WD (2009-2014)
Kia - Soul I 1.6 (2009-2013)
Kia - Soul II 1.6 (2014-)
Suzuki - Dzire 1.2 (2018-)
Suzuki - Ertiga 1.5 (2019-)
